Our power units are assembled right here in the United States and shipped all over the world. The power units work with all of our hydraulic submersible pumps which are also manufactured in the USA. The hydraulic power units are suitable for the following operations.
Dredging Operations
Digesters
Sewer Bypass
Construction Sites
Lagoons
Petro / Chemical Plants
Power Plants
Pulp & Paper Mills
Vacuum Trucks
Waste Water Treatment Plants
Mines
Lift Stations
Flood Water Control Areas
Marinas
Catfish ponds
Cranberry Bogs
Irrigation
Dairy Farms
Booster Pumps
General
Overall length: 11’-6” (3.51 m)
Overall width: 6’-0” (1.83 m)
Height: 5’-8” (1.73 m)
Fuel capacity: 112 gallons (423.96 l)
Wet weight: 3,100 lb.(1 1/2 tons)
Hydraulic Oil Capacity: 50 Gal. (189.27 l)
(Dimensions based on skid mounted unit)
Engine
John Deere 4045D diesel, water cooled with residential grade silencer, rated 61 BHP (75 kW) @ 2000 RPM. Murphy gauges, alarms, and shutdown systems.
Hydraulic System
Suction strainer, return filters, relief valves, low oil shutdown, and temperature shutdown protect the hydraulic system. All units are equipped to allow any and all modifications or repairs with minimal oil loss.
Optional Equipment
Skid Mount
Electric or Hydraulic Telescoping Picker Crane Utility Basket
Slurry Circuit Tool Circuit Electric Brakes
Hydraulic Surge Brakes
Features
All units have bottom mounted fuel tank, which provides a lower center of gravity for more stability and larger fuel capacities. The submersible pumps or tooling being used can run dry, stall, or jam, without damaging the power unit. System requires no other power source allowing operation in remote areas. The axle, fenders, and tongue is easily removed to produce a skid mounted unit. Single point lifting bail allows easy mobilization for skid or trailer mounted units.
NOTE: Specifications may change due to continual product improvement.
